Genesis GXP Series User Manual

© 2016 Genesis Attachments, LLC
Genesis GXP Jaw Armor
14
SET-UP AND TACK PROCEDURE
Chin Front and Chin Top
Place Item 3 against the front of the chin while maintaining dimensions “F” and clamp in place
(See Figures 14a, 15a & 15b). Center Item 4 from side to side and maintain dimension “D”. Use
spacers (See Figure 15a) if necessary to hold the dimension required between the plates to achieve
the correct size welds (See Figures 14a & 14b).
4
3
Figure 14b
3
Figure 14a
A
F
F
F
Typ.
A
Typ.
D
(
D
