Genesis GXP Jaw Armor
19
SET-UP AND TACK PROCEDURE
Upper Front
Place Item 7 on the top of the upper jaw (See Figure 19a & 19b). Make sure the plate has the
required width on all sides for the correct size weld. Clamp ush to the jaw prole and tack weld in
place.
D
7
A
D
7
Figure 19a
Figure 19b
Figure 19c
