TYPICAL SECTIONAL DOOR INSTALLATION
FOR HELP-1.800.354.3643 OR WWW.GENIECOMPANY.COM
TYPICAL SUPPORT
BRACKET
(NOT PROVIDED)
EXTENSION SPRING
OR
TORSION SPRING
SAFE-T-BEAM
®
SENSORS
BRACES
ADDED
HEADER BRACKET
MOUNTING BOARD
POWER CORD
(APPROX. 45 IN.)
TO 120V GROUNDED
OUTLET
4
1
3
6
2
3
5
SECTIONAL DOOR
Pg. 19
Pg. 13
Pg. 12-13
Pg. 14
Pg. 11
Pg. 17-18
Pg. 17-18
MAX. 6"
MIN. 5"
Pg. 25
To reduce the risk of injury to persons or
damage to property - Use this opener only
with sectional doors.
WARNING
7
NOTE: This opener is designed for
use with SECTIONAL doors only.
