Genie GR-12 Operator's Manual

Sixth Edition • First Printing Operator's Manual
Specifications
Part No. 1297723GT GR
™
-12 • GR
™
-15 • GR
™
-20 55
Specifications
Model
GR-12
Height, working maximum
indoor
17 ft 4 in
5.3 m
Height, working maximum
outdoor
15 ft 1 in
4.60 m
Height, platform maximum
indoor
11 ft 4 in
3.5 m
Height, platform maximum
outdoor
9 ft 1 in
2.8 m
Height, stowed maximum
70 in
177.8 cm
Width
29.5 in
74.9 cm
Length, stowed
53 in
134.6 cm
Length, platform extended
(option)
73.3 in
1.85 m
Platform dimensions, all models (length x width)
Standard platform
35 x
29.5 in
88.9 x
74.9 cm
Standard platform with
extension extended
55 x
29.5 in
139.7 x
74.9 cm
Maximum capacity, standard
platform
500 lbs
227 kg
Maximum wind speed, outdoors
28 mph
12.5 m/s
Maximum wind speed, indoors
0 mph
0 m/s
Turning radius (inside)
0 in
0 cm
Turning radius (outside)
52 in
132.1 cm
Ground clearance
2.5 in
6.5 cm
Weight
1681 lbs
763 kg
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Power source
4 Batteries, 6V 225AH
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
3500 psi
241 bar
Tire size
10 x 3 x 1 in
25.4 x 7.6 x 2.5 cm
Airborne noise emissions
Sound pressure level at ground
workstation
<70 dBA
Sound pressure level at platform
workstation
<70 dBA
Vibration value does not exceed
2.5 m/s
2
Maximum slope rating, stowed
position
30% (16.7°)
Maximum side slope rating, stowed
position
30% (16.7°)
Note: Slope rating is subject to ground conditions with
one person in the platform and adequate traction.
Additional platform weight may reduce slope rating.
Maximum allowable chassis inclination
Parallel to lift structure
3.0°
Perpendicular to lift
structure
1.5°
Drive speeds
Stowed, maximum
2.5 mph
40 ft/10.9 sec
4.0 km/h
12.2 m/10.9 sec
Platform raised,
maximum
0.5 mph
40 ft/55 sec
0.8 km/h
12.2 m/55 sec
Floor loading information
Tire load maximum
680 lbs
308 kg
Tire contact pressure
104.62 psi
7.36 kg / cm
2
721.3 kPa
Occupied floor pressure
200.87 psf
980.7 kg / m
2
9.62 kPa
Note: Floor loading information is approximate and
does not incorporate different option configurations. It
should be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.

Genie GR-12 Specifications

General

Machine Width	1.2 m
Machine Length	2.44 m
Machine Height	2.54 m
Power Source	Electric
Stowed Height	2.54 m
Drive Speed - Lowered	4.8 km/h
Turning Radius (Inside)	2.44 m
Platform Width	1.12 m
Tire Type	Non-marking
Travel Speed	4.8 km/h
Ground Clearance	0.1 m
Overall Length	2.44 m
Overall Width	1.2 m
Overall Height	2.54 m
