Operator's Manual Third Edition • Second Printing
2 GR-12 • GR-15 • GR-20 Part No. 97773
Tip-over Hazards
Occupants, equipment and materials must not
exceed the maximum platform capacity or the
maximum capacity of the platform extension.
Weight in trays and in each bike rack is part of the
total platform load.
Maximum capacity - GR-12 and GR-15
Standard platform
Platform without extension 500 lbs 227 kg
Platform retracted 500 lbs 227 kg
Platform extended - Platform only 250 lbs 113 kg
Platform extended - Extension only 250 lbs 113 kg
Work station tray (option) 50 lbs 22 kg
Parcel tray (option) 150 lbs 68 kg
Maximum occupants 1
Stock Picker platform
Platform capacity 500 lbs 227 kg
Adjustable work station tray 150 lbs 45 kg
Parcel tray (option) 150 lbs 68 kg
Bike rack (option) (each) 45 lbs 20 kg
Maximum occupants 1
AWP and fiberglass platform 350 lbs 159 kg
Maximum occupants 1
SAFETY RULES
Electrocution Hazards
This machine is not electrically insulated and will
not provide protection from contact with or
proximity to electrical current.
Maintain safe distances from electrical power lines
and apparatus in accordance with applicable
governmental regulations and the following chart.
Voltage Minimum Safe
Phase to Phase Approach Distance
Feet Meters
0 to 300V Avoid Contact
300V to 50KV 10 3.05
50KV to 200KV 15 4.60
200KV to 350KV 20 6.10
350KV to 500KV 25 7.62
500KV to 750KV 35 10.67
750KV to 1000KV 45 13.72
Allow for platform movement, electrical line sway or
sag and beware of strong or gusty winds.
Keep away from the machine if it contacts
energized power lines. Personnel on the ground or
in the platform must not touch or operate the
machine until energized power lines are shut off.
Do not operate the machine during lightning or
storms.
Do not use the machine as a ground for welding.
500 lbs / 227 kg Extension only
250 lbs / 113 kg
Platform only
250 lbs / 113 kg
