Operator's Manual
Third Edition • Second Printing
Part No. 97773 GR-12 • GR-15 • GR-20 3
SAFETY RULES
Do not raise the platform unless the machine is on
a firm, level surface.
Do not depend on the tilt alarm as a level indicator.
The tilt alarm sounds only when the machine is on
a slope.
If the tilt alarm sounds:
Lower the platform immediately. Move the machine
to a firm, level surface. If the tilt alarm sounds
when the platform is raised, use extreme caution to
lower the platform.
Do not alter or disable the limit switches.
Do not drive over 0.5 mph / 0.8 km/h with the
platform raised.
Use extreme care and slow speeds while driving
the machine in the stowed position across uneven
terrain, debris, unstable or slippery surfaces and
near holes and drop-offs.
Do not drive the machine on a slope that exceeds
the slope and side slope rating of the
machine.Slope rating applies to machines in the
stowed position.
Maximum slope rating, stowed position 30% (17°)
Maximum side slope rating,
stowed position 30% (17°)
Note: Slope rating is subject to ground conditions
and adequate traction.
Maximum capacity - GR-20
Standard platform
Platform without extension 350 lbs 159 kg
Platform retracted 350 lbs 159 kg
Platform extended - Platform only 100 lbs 45 kg
Platform extended - Extension only 250 lbs 113 kg
Maximum occupants 1
Stock Picker platform
Platform capacity 350 lbs 159 kg
Adjustable work station tray 150 lbs 45 kg
Bike rack (option) (each) 45 lbs 20 kg
Maximum occupants 1
AWP and fiberglass platform 350 lbs 159 kg
Maximum occupants 1
350 lbs / 159 kg
Extension only
250 lbs / 113 kg
Platform only
100 lbs / 45 kg
