First Edition • Third Printing Operator's Manual Supplement
Introduction
Part No. 82518GT Panel Cradle 3
Modification Approval
These instructions constitute authorization to
modify a Genie Boom listed below by attaching
hardware to the platform rails for the purpose of
lifting solid panels, provided the criteria herein is
strictly adhered to.
This option is only approved for use on models
equipped with a 6 ft or 8 ft / 1,8m or 2,4m platform.
Approved models
Foam-filled tires required
Model Serial Number
S-40
S-40 HF (CE / UK models)
S-40 XC
S-45
S-45 HF (CE / UK models)
S-45 XC
S-60
S-60HC
S-60 J
S-60 TRAX
S-65
S-65 TRAX
S-65 XC (CE / UK models)
S-80
S-80X
S-80 XC (CE / UK models)
S-85
S-85 XC (CE / UK models)
SX-135 XC (CE / UK models)
Model
Serial Number
Z-45/22
from SN Z45-00001
Z-45/22
Not approved for models
before SN 4593-3613
Z-45/25 RT
Z-45 FE (CE / UK models)
Z-45 XC (CE / UK models)
Z-60/34
Z-60/37DC (CE / UK models)
Z-60/37FE (CE / UK models)
Z-62/40 (CE / UK models)
Z-80/60 (CE / UK models)
Do not install a panel
cradle assembly on any
Genie boom product other
than the designated
models.
Components of Kit 94493:
Part Number Description
Qty
1251600GT U-bolt, 3/8 -16 x 1.5 x 2.5 x 1.25,
UNC, ZAG
2
1274322GT Nut – Nylock, Flange, 3/8 -16, F, ZAG 8
1277924GT Nut - Nylock, Flange, 1/4 -20, F, ZAG 1
1256855GT Screw - HHF, 1/4 -20 x 0.625, 8, ZAG 1
1283028GT Nut, LP Nylock, 3/8 -16, 2, ZAG 4
56934GT Rubber bumper 4
56424GT Clamp 1
88377-1400GT Padding, 3.5 OD x 1.25 ID x 14 in 2
228848GT Panel cradle base 2
228849GT Hook piece 2
73463-1175GT Tube - Aluminum, 1.25 x 0.083 2
77664GT Strap assembly 1
82487GT Decal - Symbol, Read the Manual 2
82518GT Installation Instructions 1
