REV C
Section 2 • SpecificationsJune 2005
Part No. 52075 TMZ-34/19 2 - 1
Specifications
Machine Specifications
Batteries
Type 6V DC
Group T-105
Quantity 4
Battery capacity 225AH
Reserve capacity @ 25A rate 447 minutes
Fluid capacities
Hydraulic tank capacity 1.5 gallons
5.7 liters
Hydraulic system capacity 2.25 gallons
(including tank) 8.5 liters
Tires and wheels - ANSI, CSA
Tire size ST195/75-D14
Wheel lugs 5 @
1
/2 -20
Lug nut torque, dry 90 to 120 ft-lbs
122 to 162 Nm
Tire pressure (cold) 65 psi
4.5 bar
Tires and wheels - CE
Tire size 195/65R15 91T
Wheel lugs 5 @
1
/2 -20
Lug nut torque, dry 90 to 120 ft-lbs
122 to 162 Nm
Tire pressure (cold) 44 psi
3 bar
Tongue jack jockey wheels
Tire size - pneumatic tire 4.00 / 3.50-4
Diameter 10 in
25.4 cm
Tire pressure, maximum (cold) 50 psi
3.4 bar
Performance Specifications
Boom function speeds, maximum
from ground controls (no weight in platform)
Jib boom up 10 to 15 seconds
Jib boom down 13 to 18 seconds
Primary boom up 30 to 35 seconds
Primary boom down 21 to 26 seconds
Secondary boom up 15 to 20 seconds
Secondary boom down 13 to 18 seconds
Turntable rotate, 358 ° 55 to 60 seconds
Airborne noise emissions 70 dB
Maximum sound level at normal operating workstations
(A-weighted)
For operational specifications, refer to the
Operator's Manual.
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.
