Genie TZ-50 Service Manual

Part No. 824982 Genie TZ-50 3 - 5
September 2014 Section 3 • Scheduled Maintenance Procedures
Maintenance Inspection Report
Checklist B Y N R
B-1 Batteries
B-2 Electrical wiring
B-3 Electrical Contactor
B-4 Manual override
B-5 Hydraulic oil analysis
B-6 Axle maintenance
B-7 Tongue jack
B-8 Parking brake
B-9 Wheel bearings
B-10 Hitch
B-11 Axle maintenance
Perform every 300 hours:
B-12 Engine maintenance
(if equipped)
Checklist C Y N R
C-1 Grease platform
overload (if equipped)
C-2 Test platform overload
(if equipped)
C-3 Axle maintenance
C-4 Breather Cap
C-5 Axle wheel bearings
C-6 Brakes
Checklist D Y N R
D-1 Axle maintenance
D-2 Boom wear pads
D-3 Hydraulic return filter
D-4 Turntable bearing bolts
D-5 Turntable bearing wear
Checklist E - Rev A YNR
E-1 Hydraulic oil
E-2 Engine maintenance
(if equipped)
Checklist A Y N R
A-1 Manuals and Decals
A-2 Pre-operation inspect
A-3 Function tests
A-4 Engine maintenance
(if equipped)
A-5 Lug bolts - Electric
and Hydraulic Axles
A-6 Lug bolts
Mechanical Axle
A-7 Hitch maintenance
A-8 Engine maintenance
(if equipped)
Perform after 40 hours:
A-9 Perform 30 day service
Perform every 50 hours:
A-10 Engine maintenance
(if equipped)
Perform every 100 hours:
A-11 Grease rotate bearing
A-12 Engine maintenance
(if equipped)
Instructions
• Make copies of this report to use for
each inspection.
• Select the appropriate checklist(s) for
the type of inspection to be
performed.
Daily or 8 hours
Inspection: A
Quarterly or 250 hours or
3000 mile / 4800 km
Inspection: A+B
Semi-annually or 500 hours
or 6000 mile / 9600 km
Inspection: A+B+C
Annually or 1000 hours or
12,000 mile / 19,300 km
Inspection: A+B+C+D
Two year or 2000 hours
Inspection: A+B+C+D+E
• Place a check in the appropriate box
after each inspection procedure is
completed.
• Use the step-by-step procedures in
this section to learn how to perform
these inspections.
• If any inspection receives an “N”, tag
and remove the machine from
service, repair and re-inspect it. After
repair, place a check in the “R” box.
Legend
Y = yes, acceptable
N = no, remove from service
R = repaired
Comments
Model
Serial number
Date
Hour meter
Machine owner
Inspected by (print)
Inspector signature
Inspector title
Inspector company
