LOGIC E: SEMIAUTOMATIC
GATE STATUS PULSES SAFETY DEVICES
OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP EDGE
CLOSED
Opens Opens partially No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
No effect No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
WHEN OPENING
Stops Stops Stops
§ 7.4-15-oP
No effect Stops. Opens when
disengaged
Reverses to closing
for 2 seconds
OPEN
Closes Closes Stops No effect No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
WHEN CLOSING
Opens Opens Stops No effect (memorizes
OPEN)
§ 7.4-15-Ph
Stops. Opens when
disengaged
Reverses to opening
for 2 seconds*
STOPPED
Closes** Closes** No effect (OPEN disa-
bled)
No effect No effect No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
LOGIC EP: SEMIAUTOMATIC STEPBYSTEP
GATE STATUS PULSES SAFETY DEVICES
OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP EDGE
CLOSED
Opens Opens partially No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
No effect No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
WHEN OPENING
Stops Stops Stops
§ 7.4-15-oP
No effect Stops. Opens when
disengaged
Reverses to closing
for 2 seconds
OPEN
Closes Closes Stops No effect No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
WHEN CLOSING
Stops Stops Stops No effect (memorizes
OPEN)
§ 7.4-15-Ph
Stops. Opens when
disengaged
Reverses to opening
for 2 seconds*
STOPPED
Restarts in the oppo-
site direction. Always
closes after STOP
Restarts in the oppo-
site direction. Always
closes after STOP
No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled if it has to open)
No effect (OPEN disa-
bled if it has to close)
No effect (OPEN disa-
bled)
No effect (OPEN disa-
bled)
LOGIC C: DEADMAN
GATE STATUS MAINTAINED COMMANDS SAFETY DEVICES
OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP EDGE
CLOSED
Opens No effect No effect (OPEN A
disabled)
No effect (OPEN A
disabled)
No effect (OPEN B
disabled)
No effect (OPEN A
disabled)
No effect (OPEN disa-
bled)
WHEN OPENING
- Stops Stops Stops (OPEN A disa-
bled)
No effect Stops (OPEN disa-
bled)
Reverses to closing
for 2 seconds
OPEN
No effect Closes No effect (OPEN B
disabled)
No effect (OPEN A
disabled)
No effect (OPEN B
disabled)
No effect (OPEN B
disabled)
No effect (OPEN disa-
bled)
WHEN CLOSING
Stops - Stops No effect Stops (OPEN B disa-
bled)
Stops (OPEN disa-
bled)
Reverses to opening
for 2 seconds*
