Genmitsu 3020-PRO MAX V2 - Wiring

14
Wiring
The new 3020-PRO MAX V2 is equipped with an all new Control board with auxiliary accessory ports allowing you to easily expand
your machine and workflow.
X-axis Motor
Offline Controller Z-Probe Kit
X Y Z
Limit Switch
Emergency
Stopping Switch
Y-axis Motor Z-axis Motor Spindle Motor
Handwheel Air Pump
Power Switch
USB Connecting Cable
Laser Module
Power Cord
