STEP 6: Install New Aluminum Profiles
10
Insert the screws through the round holes of the rear bar, align them with the screw holes of the new
aluminum profiles, then screw them into the threaded holes and tighten them.
(4) Rear Bar
Fixing Screw
Rear Bar
New Aluminum Profile
(4) Rear Bar
Fixing Screw
Rear Bar
New Aluminum Profile
