Genmitsu 3020-PRO MAX - Page 23

(8) M5×22 Round Head Screw
Left Stand Plate
Aluminum Proflie
STEP 13: Install the Gantry
21
3. Align the gantry left stand plate holes with the profile holes.
4. Insert (8) M5×22 screws through the left plate holes, then screw them into the profile holes and tighten
them.
