STEP 14: Wiring
23
2. Wire the Y-Axis limit switch cable as the original.
3. After completing the wiring, place the cable in the profile slot and press the seal into the slot.
Y-Axis Limit Switch Cable
Y-Axis Limit
Switch Cable
Section Seal of
Aluminum Profile
Y-Axis Limit
Switch Cable
