STEP 2: Remove the Original Screw Rod
29
Note: After completing this step, you will remove the following parts from the original machine. Make sure
to keep them organized so that the installation process goes smoothly.
1. Loose the fixing screws of the lead screw.
2. Turn the knob until the lead screw is released from the lead screw
holder, and remove the original lead screw.
T-brass Nut Spring
Knob
Lead Screw
Holder
Original Lead Screw
(2) Lead Screw
Fixing Screw
To Next Page
