Genmitsu 3020-PRO MAX - Page 53

STEP 16: Wiring
51
2. Wire the Y-Axis limit switch cable as the original.
3. Secure the cables to the holder with cable ties, then cut off the excess of the cable ties.
Y-Axis Limit Switch Cable
Y-Axis Limit
Switch Cable
Section Seal of
Aluminum Profile
Y-Axis Limit
Switch Cable
