Mechanical Installation
Collet Replacement Instruction
1. Remove the collet nut.
2. Press the collet in the direction of the arrow to separate it from the collet nut.
3. Place the collet to be replaced in the collet nut and push the collet into the collet nut in the direction of the arrow until a click is
heard, indicating that the collet is in place.
22
Point of Effort
PUSH
