6. How to Operate Your Electric Bicycle
1. Battery Indicator Switch – Press to see how much battery
charge remains.
2. Battery Indicators – The amount of power remaining is indicated
in five levels including the last indicator blinking. Recharge the
battery when two or fewer indicators are shown.
3. Handle – Rotate and hold the lock to the left and pull the handle
to remove the battery.
4. Recharging Inlet – Located beneath the on/off switch. Connect
the recharging jack here.
Definitions of Highlighted Parts
Recharging the Battery
Recharging Indictor
Green - Fully charged
Red - Charging
1. Set the battery in the slot so that the part
marked with reaches the corner as
shown in the figure on the left.
2. Press the battery on the part where the
handle is until it latches into place.
1. Ensure that the e-bike is at a standstill.
2. Rotate the battery lock counter-clockwise
to unlock.
3. With the lock rotated, pull the handle to
remove the battery.
(As mounted)
How to Remove the Battery
How to Mount the Battery
4 1
1
3
2
1. Connect the charger to the battery pack.
2. Connect the charger to an 110v power outlet.
3. Monitor the charging progress by the colored LED lights. When
the light is red, the battery is charging. When the light is green,
charging has completed.
4. Once charging has completed, disconnect the charger from the
outlet, remove the charger from the battery pack, and return the
battery to your e-bike.
• Do not move the charger and battery while charging is
in progress.
• Use the charger in a well-ventilated place free from moisture.
Do not leave anything flammable or explosive near
the charger.
• Ensure that the charger is out of reach of children.
• Only use the certified charger provided and always follow the
instructions to recharge correctly.
• Do not recharge the battery for more than 18 hours as this
could critically damage the battery pack.
• To extend the batteryʼs life, recharge it immediately after it
has discharged.
