3 Instrument Components
f
h
e
a
c
d
b
g
c
18440_001
a Optical sight
b Levelling bubble
c Ports for SD card and mini USB
d RS232C port
e Focusing telescope image
f Eyepiece; focusing graticule
g Clamping screw
h Vertical drive
Instrument com-
ponents part 1 of
2
Instrument Components 14
en
