GeoMax Zoom75 User Manual

2 Instrument Components
a b
h
i
j
c fed g
21216_002
a Carry handle
b Optical sight
c Telescope, integrating EDM, AiM, NavLight,
Scout*
d NavLight flashing diode - yellow and red
e Scout, transmitter*
f Scout, receiver*
g Coaxial optics for angle and distance
measurement, and exit port of visible laser
beam for distance measurements
h Communication side cover
i Horizontal drive
j Tribrach securing screw
*Zoom95 only
Instrument com-
ponents part 1 of
2
Instrument Components 12
