GeoMax Zoom90 Quick Guide

Zoom90 | 8Instrument Components
en
2 Instrument Components
Instrument
components part
1 of 2
a) Carry handle
b) Optical sight
c) Telescope, integrating EDM, AiM,
NavLight, Scout
d) NavLight flashing diode - yellow
and red
e) Scout, transmitter
f) Scout, receiver
g) Coaxial optics for angle and
distance measurement, and exit
port of visible laser beam for
distance measurements
h) Communication side cover
i) Horizontal drive
j) Tribrach securing screw
a b
h i
j
c fed g
009835_001
