Locations of laser
apertures
The product must not be disposed with household waste.
a) LED beam red
(NavLight)
b) LED beam yellow
(NavLight)
c) Laser beam (Scout)
d) Laser beam (EDM, AiM)
e) Laser beam (Laser
plummet)
f) Exit for laser beam
(Laser plummet)
a
c
b
e
f
d
