GeoVision GV-BL5310 User Manual

Ultra Bullet Camera
10
10.2 Features
• Image sensor
Camera Model Image Sensor
GV-UBL1211 1/3’’ progressive scan CMOS
GV-UBL1301 Series 1/2.5’’ progressive scan CMOS
GV-UBL1511 1/3’’ progressive scan super low lux CMOS
GV-UBL2511
1/2.8’’ progressive scan super low lux
CMOS
GV-UBL2411 / 3411
GV-UBL2401 Series
GV-UBL3401 Series
1/3.2’’ progressive scan CMOS
• Dual streams from H.264 or MJPEG
• Frame rate
Camera Model Frame Rate
GV-UBL1211 / 1511
GV-UBL1301 Series
30 fps at 1280 x 1024
GV-UBL2411 / 2401 Series
GV-UBL2511
30 fps at 1920 x 1080
GV-UBL3411 / 3401 Series 20 fps at 2048 x 1536
• Motorized varifocal lens for remote focus/zoom adjustment
(for GV-UBL1211 / 1511 / 2411 / 2511 / 3411 only)
• Day and night function (with removable IR-cut filter)
• Wide Dynamic Range Pro (WDR Pro) (for GV-UBL2411 / 3411 / 2401
Series / 3401 Series only)
• Defog
• Ingress protection (IP67)
• Vandal resistance (IK10 for metal casing)
• One alarm input and sensor output
115

GeoVision GV-BL5310 Specifications

General

Total megapixels	5 MP
Maximum resolution	2560 x 1920 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1280 x 960, 1280 x 720 (HD 720), 640 x 480 (VGA)
Pan range	0 - 360 °
White balance	Auto
Tilt angle range	90 - 180 °
Angle of rotation	360 °
Camera shutter type	Electronic
Camera shutter speed	1/8000 s
Minimum illumination	0 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/2.5 \
Optical zoom	- x
Focal length range	4.5 - 9 mm
Compatible memory cards	microSD (TransFlash), SDHC, SDXC
LED type	IR
Night vision distance	15 m
Number of illumination LEDs	16
Type	IP security camera
Certification	CE, FCC, C‐Tick, RoHS compliant
GPS (satellite)	No
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Form factor	Bullet
Mounting type	Wall
Product color	White
International Protection (IP) code	IP67
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	2-way
Signal-to-Noise Ratio (SNR)	45 dB
Cabling technology	10/100Base-T(X)
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP), ONVIF (Profile S)
DC output voltage	+12V
Power consumption	350 mA
Power source type	PoE
Power consumption (typical)	12.48 W
Cables included	LAN (RJ-45)
Sustainability certificates	RoHS
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	148.95 mm
Width	87.75 mm
Height	289.02 mm
Weight	1400 g
Cable length	1 m
