Remote Configurations
83
6
6.2.2 Input/Output Settings
The GV-Compact DVR V2 can connect up to 4 input devices, such as sensors.
Normal State: Set up the input state to trigger actions by selecting Open Circuit (N/O) or
Grounded Circuit (N/C).
Latch Mode: Enable the mode to have a momentary output alarm.
Trigger Digital Output Relay: Select the output(s) to be triggered once the input is
activated.
Record: Select the camera(s) to start recording once the input is activated.
You can direct a PTZ camera to a preset point upon input trigger:
Set PTZ camera to preset point: Enable the preset function and select the camera that
maps the PTZ camera.
Input on: Direct the PTZ camera to a preset point when the input is triggered.
Input off: Direct the PTZ camera to another preset point when the triggered input is off.
Duration to set preset after input off x seconds: Specify the amount of time the PTZ
camera stays in “Input on” preset point before moving to “Input off” preset point.
Send Video to Center V2: Select the desired camera(s) to send their images to Center
V2 when the input is triggered.
Figure 6-7
Note: The input settings only function after you start Input monitoring manually or by
schedule. To configure the input monitoring, see 6.4 Monitoring.
For related PTZ settings, see 6.2.1 PTZ Settings.
