GeoVision GV-CS1320 User Manual

viii
Optional Device
Optional devices can expand the capabilities and versatilities of your GV-CS1320. Consult
your sales representative for more information.
GV-Reader 1352
V2
GV-Reader 1352 V2 is a card reader that uses a 13.56 MHz frequency.
It has both Wiegand and RS-485 outputs that can be connected to any
standard access control panel.
GV-RK1352
GV-RK1352 is a card reader with keypad that uses a 13.56 MHz
frequency. The reader has both Wiegand and RS-485 outputs that can
be connected to any standard access control panel.
GV-R1352
GV-R1352 is a card reader that uses a 13.56 MHz frequency. The
reader has both Wiegand and RS-485 outputs that can be connected to
any standard access control panel.
GV-DFR1352
GV-DFR1352 is a card reader that uses a 13.56 MHz frequency. The
reader has both Wiegand and RS-485 outputs that can be connected to
any standard access control panel.
GV-CR420
GV-CR420 is a card reader with a built-in 4MP wide angle IP camera.
The card reader recognizes identification cards and transmits live view
through network connection.
GV-GF Fingerprint
Readers
GV-CS1320 is compatible with GV-GF1921 / 1922. The reader
supports three operation modes: Fingerprint Only, Fingerprint + Card
and Card Only. In Fingerprint Only mode, the fingerprints are enrolled
through GV-ASManager. In Fingerprint + Card mode, the fingerprint
templates are stored on the user card. In Card Only mode, the users
only need to swipe the card to be granted access. Readers with optical
and capacitance sensors are available.
GV-FR2020
GV-FR2020 is a face recognition reader that uses a 13.56 MHz
frequency. The reader supports two operation modes: Face
Recognition and Card. In Face Recognition mode, the user data are
distributed through GV-ASManager to the assigned reader where the
face templates are stored. In Card mode, the users must first have an
ID number enrolled using GV-ASManager connected with the reader.
Push Button
Switch
The push button switch can be integrated with access control system,
allowing door exit by momentarily activating or deactivating the electric
locking device. Both American standard and European standard push
buttons are available.
GV-IB25 / 65 / 85
Infrared Button
The GV-IB25 / 65 / 85 Infrared Button detects infrared movement within
3 to 12 cm and allows you to open the door with a wave of hand.
Electric Lock
Three types of electric locks are available: electromagnetic lock, electric
bolt and electric strike.
GV-AS ID Card &
GV-AS ID Tag
GV-AS ID Cards and GV-AS ID Tags are ideal for business and
residential environment, where access control is important for security
reasons. 13.56 MHz cards and tags are available.

GeoVision GV-CS1320 Specifications

General

Type	IP security camera
Certification	CE, FCC, RCM, RoHS
Day/night mode	Yes
Languages support	CHI (TR), ENG, ESP, FRE, POR, RUS
Number of languages	6
Operating frequency	13.56 MHz
Placement supported	Outdoor
Connectivity technology	Wired
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 \
Number of effective pixels (H x V)	1920 x 1080 pixels
White balance	Auto, Manual
Camera pan control	No
Camera shutter type	Electronic
Camera shutter speed	1/5 s
Minimum illumination	0.02 lx
Adjustment shutter speed	Auto/Manual
Field of view (FOV) angle	180 °
Audio formats supported	AAC, G.711
Signal-to-Noise Ratio (SNR)	52 dB
LED type	IR
Night vision distance	3 m
Number of illumination LEDs	2
Fixed focal length	1.7 mm
Focal length range	1 - 1 mm
Maximum aperture number	2.5
Total megapixels	2 MP
Video formats supported	H.264, M-JPEG
Wi-Fi	-
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMARTSP, PSIA, SNMP, QoS(DSCP), ONVIF(ProfileS)and(ProfileC)
Compatible memory cards	MicroSD (TransFlash)
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
DC output current	2.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	25.5 W
Sustainability certificates	RoHS
Mounting type	Wall
Product color	Black
International Protection (IP) code	IP66
Memory card included	MicroSD
Included memory card size	2 GB

Weight and Dimensions

Depth	34.5 mm
Width	80 mm
Height	137 mm
Weight	315 g
