GeoVision GV-CS1320 User Manual

Administrator Mode
73
4
[Dynamic DNS Server Settings]
DDNS (Dynamic Domain Name System) provides a convenient way of accessing GV-
CS1320 when using a dynamic IP. DDNS assigns a domain name to GV-CS1320, so that
the Administrator does not need to go through the trouble of checking if the IP address
assigned by DHCP Server or ISP (in xDSL connection) has changed.
Before enabling the following DDNS function, the Administrator should have applied for a
Host Name from the DDNS service provider’s website. There are 3 providers listed in GV-
CS1320: GeoVision GVDIP, GeoVision DDNS Server and DynDNS.org.
To enable the DDNS function:
1. Enable: Enable the DDNS function.
2. Service Provider: Select the DDNS service provider you have registered with.
3. Host Name: Type the host name used to link to GV-CS1320. For users of GeoVision
DDNS Server, it is unnecessary to fill the field because the system will detect the host name
automatically.
4. User Name: Type the user name used to enable the service from the DDNS.
5. Password: Type the password used to enable the service from the DDNS.
6. Click Apply.
[HTTPS Settings]
By enabling the Hypertext Transfer Protocol Secure (HTTPS) settings, you can access GV-
CS1320 through a secure protocol. You can use self-generated Certificate File and
Certificate Key File or the ones verified by the SSL authority. Click Browse to locate the
Certificate File and Certificate Key File and type the password if the .pem files are protected
by password. Click Apply. The Web interface will be restarted and you will need to log in
again.
Note: The .pem file format is supported by the Certificate File and Certificate Key File.
[GV-IPCAM Streaming Port Settings]
The VSS port enables your GV-CS1320 to be connected to the GV-System / GV-VMS and to
send images to GV-ASManager. The default setting is 10000.

GeoVision GV-CS1320 Specifications

General

Type	IP security camera
Certification	CE, FCC, RCM, RoHS
Day/night mode	Yes
Languages support	CHI (TR), ENG, ESP, FRE, POR, RUS
Number of languages	6
Operating frequency	13.56 MHz
Placement supported	Outdoor
Connectivity technology	Wired
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 \
Number of effective pixels (H x V)	1920 x 1080 pixels
White balance	Auto, Manual
Camera pan control	No
Camera shutter type	Electronic
Camera shutter speed	1/5 s
Minimum illumination	0.02 lx
Adjustment shutter speed	Auto/Manual
Field of view (FOV) angle	180 °
Audio formats supported	AAC, G.711
Signal-to-Noise Ratio (SNR)	52 dB
LED type	IR
Night vision distance	3 m
Number of illumination LEDs	2
Fixed focal length	1.7 mm
Focal length range	1 - 1 mm
Maximum aperture number	2.5
Total megapixels	2 MP
Video formats supported	H.264, M-JPEG
Wi-Fi	-
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMARTSP, PSIA, SNMP, QoS(DSCP), ONVIF(ProfileS)and(ProfileC)
Compatible memory cards	MicroSD (TransFlash)
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
DC output current	2.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	25.5 W
Sustainability certificates	RoHS
Mounting type	Wall
Product color	Black
International Protection (IP) code	IP66
Memory card included	MicroSD
Included memory card size	2 GB

Weight and Dimensions

Depth	34.5 mm
Width	80 mm
Height	137 mm
Weight	315 g
