Administrator Mode
83
4
[Host Settings] Enter a descriptive name for GV-CS1320.
[Auto Reboot Setup] Select Enable to activate automatic reboot and specify the time for
reboot in the sub fields.
Day Interval: Type the day interval between each automatic reboot.
Reboot Time: Use the drop-down lists to specify the time for automatic reboot.
[Firmware Update] Displays the firmware version of GV-CS1320.
[System Settings]
Clicking the first Load Default button will restore GV-CS1320 to factory default settings.
Clicking the second Load Default button will restore GV-CS1320 to factory default settings
(Except network).
Note: After clicking the first default function, you will need to configure the camera access
controller’s network setting again.
[Internal Temperature] Displays the chipset temperature inside GV-CS1320.
[Reboot] Click the Reboot button will make GV-CS1320 perform the software reset.

Table of Contents

Other manuals for GeoVision GV-CS1320

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the GeoVision GV-CS1320 and is the answer not in the manual?

GeoVision GV-CS1320 Specifications

General IconGeneral
TypeIP security camera
CertificationCE, FCC, RCM, RoHS
Day/night modeYes
Languages supportCHI (TR), ENG, ESP, FRE, POR, RUS
Number of languages6
Operating frequency13.56 MHz
Placement supportedOutdoor
Connectivity technologyWired
Sensor typeCMOS
Number of sensors1
Optical sensor size1/2.8 \
Number of effective pixels (H x V)1920 x 1080 pixels
White balanceAuto, Manual
Camera pan controlNo
Camera shutter typeElectronic
Camera shutter speed1/5 s
Minimum illumination0.02 lx
Adjustment shutter speedAuto/Manual
Field of view (FOV) angle180 °
Audio formats supportedAAC, G.711
Signal-to-Noise Ratio (SNR)52 dB
LED typeIR
Night vision distance3 m
Number of illumination LEDs2
Fixed focal length1.7 mm
Focal length range1 - 1 mm
Maximum aperture number2.5
Total megapixels2 MP
Video formats supportedH.264, M-JPEG
Wi-Fi-
Ethernet interface typeFast Ethernet
Supported network protocolsHTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMARTSP, PSIA, SNMP, QoS(DSCP), ONVIF(ProfileS)and(ProfileC)
Compatible memory cardsMicroSD (TransFlash)
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)10 - 90 %
DC output current2.5 A
DC output voltage12
Power source typeDC, PoE
Power consumption (max)25.5 W
Sustainability certificatesRoHS
Mounting typeWall
Product colorBlack
International Protection (IP) codeIP66
Memory card includedMicroSD
Included memory card size2 GB
Weight and Dimensions IconWeight and Dimensions
Depth34.5 mm
Width80 mm
Height137 mm
Weight315 g
