PT Camera

20. PT Camera

20.1 Packing List

• GV-PT130D/220D/320D

• Mounting Base

• Mounting Cover

• Wall Mount Bracket

• Screw Anchor x 3

• Long Screw x 3

• Short Screw x 3

• Round Screw x 3

203
