12.4 Connecting the Camera
12.4.1 Wire Definition
The data cable provides connections for power, ground and network access.
The wires are defined below:
No. Wire Color Definition
1 Red DC 12V
2 Black Ground
3 Black (thick) PoE, Ethernet
