PTZ Camera
12
12.8.7 Auto Pan Settings
For the PTZ Camera to survey a horizontal view, establish an Auto Pan.
Up to 4 sets of Auto Pan can be created.
Configuring an Auto Pan
To configure a horizontal movement:
1 Adjust the angle of the camera view using the
Up and Down
Control
buttons since any vertical movements of the camera will not
be recorded by Auto Pan.
2 On the control panel, click the
Option button (No. 6, Figure 12-15),
select
Auto and select a Set Auto Pan number.
3 Click the
Right or the Left Control buttons on the PTZ control panel
to perform the desired movement.
4 Click the
Option button (No. 6, Figure 12-15), select Auto and
select an
End Auto Pan number to save this configuration.
177
