Fixed IP Dome

16.1 Packing List

16.1.1 Packing List for Hard-Ceiling Mount

• Fixed IP Dome

• Torx Wrench

• Mounting Plate

• Short Screw Anchor x 3

• Ceiling Screw x 3

• Plate Screw x 3

• TV-out Wire

• Sticker

• Power Adapter • GV-IPCAM H.264 Software

DVD

• GV-IPCAM H.264 Quick

Start Guide

• GV-NVR Software DVD

• GV-NVR Quick Start Guide

Note: The power adapter can be excluded upon request.
