GEPRC CineLog35 User Manual

7 / 18
Bind TBS NanoRX:
1. For Taranis X9D/X9D Plus/X9E and Taranis QX7, turn on the transmitter, go to the
TOOLS – CROSSFIRE SETUP – XF Micro TX ,and select Bind.
2. Turn on the receiver while holding the bind button on the receiver, release the button
and the green light on flash .and then holding the button for 8 second ,and release. And
the green light is off and the red light is flashing, ‘update micro RX？’ will appear on the
transmitter screen, and select ‘ENTER’.
3. Wait for the update to complete, the binding is successful, and the receiver green light is
on.
1
2
3
4
5
6
Bind Button
Binding
Binding Successful

GEPRC CineLog35 Specifications

General

Camera	Caddx Ratel 2
Frame Size	3.5 inch
Flight Controller	GEPRC GEP-F722-45A AIO
ESC	45A BLHeli_S
Propellers	3.5 inch
Battery	4S 850mAh-1300mAh
Receiver	FrSky R-XSR, TBS Nano RX
