Gerber Technology GERBERplotter Infinity Series User Manual

57
English
Symptom Cause Solution
Print is smudged
(blotchy)
Infinity 45 ink jet
cartridge is dirty.
Infinity 85 print head
cartridge is dirty
Remove ink jet
cartridge and clean
cartridge and parking
station with a clean,
lint-free cloth
moistened with de-
ionized water
Remove print head
cartridge and clean
cartridge and parking
station with a clean,
lint-free cloth
moistened with de-
ionized water
Print head is pausing
between passes
The plotter is waiting
for data from the PC
This is normal,
especially when
plotting dense plots or
plots with a lot of
annotation
Increase
communication baud
rate (Page 53)
Paper not tracking
uniformly on take-up
roll
Plotter not level
Paper not aligned
Check to make sure
plotter is level (Page
15)
Only use one piece
of tape (Figure 26)
when taping supply
paper to take-up roll,
and make sure paper
path is straight from
feed roll across platen
and onto take-up roll
