RENTAL SERIES
ELECTRICAL GENERATOR
- Displaying information:
Press this button: (11).
Page order:
- Status display.
- Instrument display.
- Alarms display.
- Event log.
It is possible to scroll through the different display screens by pressing the next page button: (10). Once
selected, the instrument will remain on the screen until the user selects a different instrument or after a period of inactivity
for the control module, at which point the default display appears.
Alternatively, by holding down on (10) the user can autoscroll through all of the instruments on a particular
s
creen. To disable scrolling, stop pressing the page down button then either press it again for a few seconds or press
(11). When autoscroll is disabled, if no buttons are pressed the display will return to the alarms page.
If an alarm becomes activated while viewing instruments, the alarms page will be automatically displayed.
Instrument page content:
- Engine speed.
- Oil pressure.
- Coolant temperature.
- Engine hours run.
- Number of starts.
- DC battery voltage.
- Generator AC voltage L-N.
- Generator AC voltage L-L.
- Generator line current.
- Fuel level (%).
- Nominal voltage L-N.
- Nominal voltage L-L.
- Nominal frequency (Hz).
I
f the following appears in an instrument display: # # # # # # , this means that the engine cannot provide this
parameter; the control module, however, can display this instrument.
If the following appears in an instrument display: # # # # # # with the electrical generator in OFF/AUTOMATIC mode
(with the engine stopped), this means that the control module is not connected to the engine.
Press this button (6) to display the given value.
