Gesipa PowerBird - Blind Rivet Setting Tool; Working Range; Equipment and Accessories; Technical Data

19
GB
1. Blind rivet setting tool
1.2 Equipment/accessories
Nosepieces: 17/45 in working position
17/36, 17/40 and 17/32 in magazine
Wrench: WAF 12 (cover for nosepiece magazine)
Hanger: Concealed in housing
Quick-change battery: 14.4 V
1.3 Technical data
Weight: 2.0 kg (with battery)
Stroke: 20 mm
Drive: DC motor 14.4 V
Setting force: 14,000 N
Noise emission: L
pa
78.5 dB
Measurement uncertainty K = 3 dB
Vibration: < 2.5 m/s²
Measurement uncertainty K = 1.5 m/s²
To avoid blockages, we recommend that you use the corresponding jaw pushers
according to table 1.4!
1.1 Working range
Rivet
Standard blind rivet
G-Bulb
All materials
BULB-TITE
®
All materials
MEGA GRIP
®
All materials
All materials Al Steel
Ø
(mm)
up to 6,4 up to 8 4,8 - 6,4 up to 4,8 up to 7,7 up to 6,4
