Gesipa Taurus 1-4 - 4 Technical Data; 5 Equipment;Accessories

18
GB
4. Technical data
Tool type
TAURUS
®
1 TAURUS
®
2 TAURUS
®
3 TAURUS
®
4
Weight (kg) 1.3 1.6 1.9 2.0
Operating pressure (bar) 5-7 5-7 5-7 5-7
Stroke (mm) 15 18 25 19
Hose connection Ø (1/4’’) (mm) 6 6 6 6
Volume of spent mandrel container approx. 100 to 200 depending on size
Air consumption (sl/rivet) approx. 1.0 approx. 2.3 approx. 4.8 approx. 4.8
Setting force at 5 bar (N) 4,200 9,000 14,000 20,000
Hydraulic oil,
Renolin Eterna 32 (ml)
approx. 30 approx. 30 approx. 30 approx. 30
Noise emission Lpa (dB)
Measurement uncertainty k = 3 dB
77 78 79 79
Vibration (m/s²)
Measurement uncertainty k = 1.5 m/s²
< 2.5 < 2.5 < 2.5 < 2.5
Compressedairquality (ltered)
   
Integrated spent mandrel evacuation
   
Integrated blind rivet intake
   
5. Equipment/accessories
Tool type
TAURUS
®
1 TAURUS
®
2 TAURUS
®
3/4
Nosepiece in working position 17/22 17/32 17/45
Nosepiece in tool base
17/20
17/18
17/24
17/29
17/27
17/40
17/36
1 wrench WAF 12/14 (144 6044)
  
1 wrench WAF 14/17 (144 6043)
  
1 bottle of hydraulic oil 100 ml (144 5294)
  
1oilrellcan (1435687)
  
