7
Ref Component Description
Camera lens Allows you to use the camera function.
Speaker Sends out sound and voice from your Tablet PC.
Touchscreen Displays and receives information for the Tablet PC.
Indicators
Camera
Lights up when the camera is in use.
Battery
Lights amber when the battery is being charged.
Lights green when charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
Blinks red (once per second) when the battery’s
capacity is below 10%.
Blinks red rapidly (once per 0.5 second) when there is
a thermal protection problem. Ask for repair service
in case this happens.
Blinks amber when the battery charging is in an
abnormal state. Replace the battery in case this
happens.
Power
Lights blue when the power is on.
Blinks blue when the system is in Sleep mode.
P1 button Starts the G-Camera application.
P2 button Enables or disables the auto rotate function.
Windows logo
button
Opens or closes the Start menu.
Plus button Increases the volume.
Minus button Decreases the volume.
Power button Turns the power on or off. (The default “off” state is
“Sleep mode.”)
Microphone Receives sound and voice to record voice.
