14
Installation instructions
5018606-00 Rev.C Edition 0704
Other points
Max outside temperature
50 °C (122 °F)
Sound level
Electrical connections
See Alternative connection arrangements
Overcurrent protection as per Curve C
Heat dissipation to the room
Max 2000W (hot air during drying).
Heat radiation to the room
Max 1100W (during disinfection at 90 °C (194 °F))
Circulation system
Design pressure 0.2 MPa
Working pressure max 0.1 MPa
Design temperature 100 °C (212 °F)
Working temperature max 93 °C (200 °F)
Environmental requirements:
Air humidity max 80% at 31°C (87 °F)
Room temperature 5 - 40 °C (41 - 104 °F)
Degree of protection
IP21
Table 1
Calculated sound power level Lw for the test object, db ref 1 pW.
Octave band frequency (Hz) 125 250 500 1000 2000 4000 8000 LwA LwAFmax
Correction terms (Kok) 63 67 62 59 58 57 54 66 83
The calculated sound power level implies different sound levels LpA in different types of space. With a larger
room volume, the sound level decreases slightly and with a smaller room level it increases slightly. Table 2 below
shows three example of what to expect in practice.
Table 2
Calculated sound level LpA for the test object in a 70m
3
room, db ref 20 μPa.
Type of room Description Operator position* 3 meters from
the machine
Hard to sound All surfaces of tile, plaster, concrete or similar, ie no
sound absorbing surfaces and no furniture 65 65
Normally-damped Some sound absorption in the form of furniture and textiles. 61 60
Damped Full-cover ceiling absorbent and some furnishing with
tables, chairs and textiles. 58 56
* Operator position means 1 meter from the machine and 1.5 meters above the floor. All values are for one
machine.
