Other points
Circulation system
Design pressure: 300 kPa
Working pressure: max 130 kPa
Design temperature 100°C (100.00°C)
Working temperature 93°C (92.78°C)
Material: EN1.4404, ASTM 316L
Waste tank
Type of vessel: not closed
Material: polypropylene
Volume 50 litres (13.21 gallons)
Max temp 95 °C (203 °F)
Process tank
Type of vessel: not closed
Material: polypropylene
Volume 50 litres (13.21 gallons)
Max temp 95 °C (203 °F)
Booster tank
Type of vessel: not closed
Material: EN1.4404 ASTM 316L
Volume 35 litres (9.24 gallons)
Max temp 99°C (98.89°C)
Circulation pump
Flow rate: Q max 1000 litres/min
Power: 2.2 kW
Material:
Pump body: EN1.4404, ASTM 316L
Pump impeller PP
Drain pump
Flow rate: Q max 50 litres/min
Power: 170 W
Material:
Pump body: PP
Impeller: PP
