Getinge 9128 - Assembly

Assembly
Installation begins with assembly of the main modules. This module is affixed to four corner supports.
Four wheels could be mounted on the supports to facilitate transportation to the pit. There are two eye
bolts that can be screwed into the corner supports. These can be used as lifting aids.
• Move the main module and the chamber extension modules to the installation space.
000523
• Measure up exactly where the module will be located. Place four pieces of metal sheeting in the
pit for the module's legs. (The sheeting makes it easier to move the module later on.)
