Gewiss RESTART RD 90 Series User Manual

20
230V
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
0
230V
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
I
230V
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
TEST
230V
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
TEST
230V
INSERIRE CON
LEVA IN
POSIZIONE I
ON OFF
TEST
DEVICE FRONT
Manual operation
CONDITION
LED SIGNALS
Restart device not cut in.
Differential switch closed.
System powered up.
Restart device
not cut in.
Differential switch tripped or opened intentionally.
System disconnected and sectioned.
Restart device
cut in.
Differential switch closed.
System powered up.
Restart device
blocked due to a fault in the system down-
stream. Attempt a manual restart. Call the installation tech-
nician if the attempt fails. Differential switch tripped.
System disconnected but not sectioned.
Restart device in the
check for presence of a fault or
reclosing phase. Opening the hatch interrupts automatic
reclosing, making the manual manoeuvre possible.
System disconnected but not sectioned.
Automatic operation
red
red
Key
LED off LED onLED blinking
LED SIGNALS

Gewiss RESTART RD 90 Series Specifications

General

Brand	Gewiss
Model	RESTART RD 90 Series
Category	Switch
Language	English
