SettingsGC 363 R / SF
ADVANCED menu
0 1 2 3 4 5 6 7 8 9
Back / Continue RAD: Filter
low > > > > > > high
RAD: Direction
Radar o
**
bi
*
uni
uni
EM
uni
AWAY
bi
**
auto
uni
**
auto
EM
**
auto
EM:
for persons with restricted mobility
AWAY:
direction detection away
from the sensor
auto:
adaptation to eld size in small shops (not suitable for FR doors)
* The bi-setting is more sensitive to the inuences of the weather. ** The setting is not permitted if the sensor is used in emergency exits.
RAD: Holding time
0.5 sec. 1 sec. 2 sec. 3 sec. 4 sec. 5 sec. 6 sec. 7 sec. 8 sec. 9 sec.
AIR: Width
+
In addition, always use a screwdriver to set the arrows for eld width on the detector.
AIR: Quantity
Service
mode
1 2
Service mode = no scanning of presence for 15 minutes (during maintenance). This value does not permit conformity of the door system with EN 16005 and DIN 18650.
AIR: Max. time
Movem. 15 sec.
30 sec.
1 min. 2 min. 5 min. 10 min. 20 min. 60 min. endless
Minimum value for DIN 18650: 1 min. Minimum value for EN 16005: 30 sec.
AIR: Output
Closer
Opener
Opener
Closer
Opener
Opener
Closer
Closer
Current
Opener
Frequency
Opener
***)
Diversion
Movem. (1)
Movem. (1) or
pres. (2)
Movem. (1)
and pres. (2)
Opening output is active in the case of: (0) Movement detection
(1) Movement or presence detection (2) Movement and presence detection
Factory settings
Reset to factory settings.
Full reset
Partial reset (outputs are not reset)
9
Back / Continue
***) Standard setting GC 363 SF
