7
DescriptionGC 339
1 Cover
2 Setting button (grey)
3 Button for setting the angle
of the AIR curtain (red)
4 AIR lens (transmitter)
5 AIR lens (interface)
6 Width adjustment of the AIR
curtain
7 LCD
8 Main connector
