GEZE Perlan AUT-NT
4
Safety
Important safety instructions3.2
To ensure personal safety, it is important to follow these instructions. à
Keep these instructions. à
The prescribed mounting, maintenance and repair work must be performed by properly trained personnel à
authorised by GEZE.
GEZE shall not be liable for injuries or damage resulting from unauthorised modication of the system. à
GEZE shall not be liable if products from other manufacturers are used with GEZE equipment. à
Only original GEZE parts may be used for repair and maintenance work. à
The connection to the power supply must be made by a professional electrician. Perform the power connec- à
tion in accordance with DIN VDE 0100-610.
The electrical installation at the customer has to have an all-pole power disconnector that can be secured reli- à
ably against reactivating (e.g. lockable switch with at least 3 mm contact opening).
A customer-side 10 A overload cut-out must be used as the line-side disconnecting device. à
Observe the latest versions of guidelines, standards and country-specic regulations, in particular: à
BGR 232 "Guidelines for power-operated windows, doors and gates" à
DIN 18650, Part 1 and 2 "Automatic door systems" à
DIN VDE 100-600 "Installation of low-voltage systems - Part 6 Tests" à
DIN EN 60335-1 "Safety of electrical devices for home use and similar purposes" à
Accident-prevention regulations, especially BGV A1 (VBG1) "General regulations", BGV A3 (VBG4) "Electrical à
systems and equipment"
Safety-conscious working3.3
Protect the workplace against unauthorised entry.
X
Use only cables specied in the cable plan and shield in accordance with the wiring diagram.
X
Before working on the electrical system disconnect the drive from the 230 V mains network and check the
X
safe isolation from supply.
Note that the system will still be supplied with power, despite the fact that the power supply is disconnected, à
if an uninterruptible power supply (UPS) is used.
Always use insulated wire-end ferrules for wire cores.
X
Danger of injury by sharp edges in the drive! à
Inspection of the mounted system3.4
Safety analysis (danger analysis)
In accordance with Machinery Directive 2006/42/EC and DIN 18650, a risk analysis must be performed and the
door system identied in accordance with CE Identication Directive 98/68/EEC before commissioning the door
system.
This includes:
Enter the classication in accordance with DIN 18650-1 on the information plate and adhere the information
X
plate onto the drive housing so that it is visible from below.
Check the measures for security and prevention of crushing, impact, shearing or drawing-in spots.
X
Check the electrical fusing. à
Check the system for avoidable operating errors. à
Additionally applicable documents3.5
Drawing No. Type
10421-9-9609 PERLAN AUT-NT wiring diagram
10421-9-9610 PERLAN AUT-NT cable plan
10421-9-9624 PERLAN AUT-NT user manual
The diagrams are subject to change.
Use only the most recent versions.
