GEZE Perlan AUT-NT
5
Transportation and storage
Transportation and storage4
CAUTION!
Damage to the PERLAN AUT-NT sliding door drive through hard knocks and falls.
Do not throw or let drop the PERLAN AUT-NT.
X
CAUTION!
Storage temperatures under –15°C and above +60°C can result in damage to the device.
Store dry. Protect from moisture during transportation and storage.
X
Tools and aids5
Tape measure à
Marking pen à
Allen key à
Screwdriver set à
Side-cutting pliers à
Crimping pliers for cables à
Wire stripper à
Multimeter à
Product description6
Technical data6.1
Mechanical data (drive)
Dimensions (WxHxL): 55 mm x 45 mm x 145 mm à
Ambient temperature: 0°C to +50°C à
Drive mass: approx. 0.75 kg à
Electrical data
Mains connection: 230 V à
Power consumption: max. 35 W, standby approx. 3.5 W à
Externally connectable devices: 24 V DC, max. 50 mA à
Function description6.2
The system is an electrical sliding door drive. The controller drives a 24 V DC motor that moves a linear sliding
door via a toothed belt.
Track6.2.1
Almost the complete technology is located in the track. In addition to the sliding and stop elements, this also
contains the drive with the corresponding guide pulleys.
Floor guide6.2.2
A oor guide is used to guide the sliding element correctly. Its use is mandatory.
Roller carriage/suspension6.2.3
The roller carriage consists of supported rollers. The leaves are fastened adjustable in height to the suspension.
Toothed belt 6.2.4
The toothed belt forms the connection to the sliding elements via pulley guides. The toothed belt is cut to size as
required and connected by means of a toothed belt lock.
