GEZE Slimdrive EMD-R Wiring Diagram

EMD / EMD-F / EMD-F-IS / EMD-F/R / EMD Invers
11
Safety sensor, open and close
4.1.2 Monitoring opening
X
Setting the parameter "Contact type":
à DPS: Set
s3
to
02
("normally open")
(factory setting).
à ST220: Set the "Input signals", "SI3 – terminal SIO",
"SI3 contact type" to "normally open"
(factory setting).
X
Setting the parameter "Function":
à DPS: Set
f3
to
05
(SIO stop) or
06
(SIO stop SF-GF).
à ST220: Set the "Input signals", "SI3 – terminal SIO",
"SI3 function" to "SIO stop" or
"SIO stop SF-GF".
1
13
10
2
SIO
SIO
GN
D
24V
TST
S
E
GY
2
1
4
3
5
BN
BK
BU
WH
SIGNAL
24V
SIO
GND
SIS
100mA
2
1
3
GC 338
Interfacemodul
1 Opposite hinge side
2 Hinge side
3 Door transmission cable
SIGNAL
Interface module
