EMD / EMD-F / EMD-F-IS / EMD-F/R / EMD Invers
4
Symbols and illustrations
Warning notices
Warning notices are used in these instructions to warn you of property damage and personal injury.
X
Always read and observe these warning notices.
X
Follow all measures that are labelled with the warning symbol and warning word.
Warning
symbol
Warning word Meaning
DANGER
Danger to persons.
Non-compliance will result in death or serious injuries.
WARNING
Danger to persons.
Non-observance may result in death or serious injuries.
CAUTION
Danger to persons.
Non-compliance may result in minor injuries.
More symbols and illustrations
In order to illustrate correct operation, important information and technical information is highlighted.
Symbol Meaning
means "important information";
information on avoiding material damage, understanding a concept or optimising workows.
means "additional information"
X
Symbol for an action: there is something you must do here.
X
If there are several actions to be taken, keep to the given order.
Conforms to
DIN 18650 / EN 16005
Symbol in a table or in information concerning safety sensors.
Does not conform to
DIN 18650 / EN 16005
Symbol in a table or in information on sensors that do not correspond to
DIN 18650 / EN 16005.
Fire protection door Symbol for re protection door
Not permissible for re protec-
tion door
Symbol "Not permissible for re protection door"
Validity
à Valid for software version DCU2 V3.0 or higher
à Hardware Revision DCU200 Rev E
à For door control units
à DCU2 for automatic swing doors
à DCU2-F for automatic swing doors, closing with spring force
à DCU2-I for automatic swing doors, opening with spring force
Product liability
In accordance with the liability of the manufacturer for their products as dened in the German "Product Liability
Act", the information contained in this brochure (product information and proper use, misuse, product perfor-
mance, product maintenance, obligations to provide information and instructions) is to be observed. Failure to
comply releases the manufacturer from their statutory liability.
