GEZE TS 5000 R User Manual

12
3 mm
5 mm
SW 3
2
5 Nm
TS 5000 R
10
5 mm
click
click
TS 5000 RFS
L R
1
14 Nm
2
14 Nm
1
3
TS 5000 R
TS 5000 RFS
TS 5000 R
TS 5000 R

GEZE TS 5000 R Specifications

General

Type	Overhead door closer
Door width	up to 1400 mm
Fire and smoke protection	Yes
Backcheck	Yes, adjustable
Closing speed	Adjustable
Latching action	Adjustable
Opening angle	up to 180°
Drive type	Mechanical
Hold-open function	Yes
