GEZE TS 5000 R User Manual

GEZE TS 5000 R / TS 5000 RFS
4
EN | English
Product description
TS 5000 R: The system contains an electrical hold-open
device for the door leaf.
TS 5000 R without integrated hold-open device: The system
does not have an integrated electrical hold-open device. The
system has been equipped with a hold-open device using a
hold-open magnet.
TS 5000 RFS: The system has an electrically actuated free-swing
device in the closer.
The systems are controlled by an integrated smoke switch con-
trol unit and are approved for installation on single leaf re and
smoke protection doors. The system is triggered if there is a re
or a power failure, and the door closes automatically
Further documents
The components supplied by GEZE include further do-
cuments describing the installation or connection of the
system. These must be read and followed.
à Door closer installation instructions
à Door closer user information
à Instructions for installation, commissioning, operation
and after-sales service maintenance of FA GC (available
at www.geze.com).
Safety notices
Follow the document “Instructions for the installation, com-
missioning, operation and after-sales service maintenance
of GEZE hold-open system FA GC” for electrical connection
and commissioning (available at www.geze.com).
DANGER!
Danger of electric shock!
Electric wiring must only be carried out by professional
electricians.
X
Interrupt power supply! Secure against reactivation.
X
A 16 A circuit breaker must be provided on site (suitable
for the electrical installations).
X
Use cable protection for the 230 V cable when leading-
through plaster.
X
Insert the cable protruding from the wall through theres-
pective openings of the smoke switch housing only.
Technical data
Protection rating
II
IP rating IP 20; only for dry rooms
Ambient temperature -5 °C bis 50 °C
230 V supply cable NYM-O, 2 x 1,5 mm
2
NYM-J, 3 x 1,5 mm
2
protective conductor insulated
Supply voltage: 230 V AC +10 % / –15 %,
Operating voltage: 24 V DC ± 15%
maximum current con-
sumption
260 mA
Installation details
The remarks are intended as work instructions as well as the
associated graphical installation instructions.
to
1
X
Drill xing holes for door closer, guide rail, smoke
switch housing (A), power supply 230V (B) and optio-
nally additional connections (C).
to
5
DANGER!
Follow safety precautions
to
6
X
Lay down the power supply line 230 V starting from the
clamp. Stow away the excess length at the powersupply
unit.
to
7
X
Protect the cable from falling out using foam padding.
to
8
X
Fit the protective cap so that the smoke switch opening
is concealed in the cover panel in order to protect the
interior of the system from contamination.
X
The protective cap must be removed when the hold-open
system is commissioned.
CAUTION!
When clipping on the cover panels do not squeeze the cables.
Fit the protective cap so that the smoke switch opening is
concealed in the cover panel in order to protect the interior of
the system from contamination before commissioning.
Initial operation
CAUTION!
The installation of the smoke switch may only take place
shortly before commissioning. If installed early, there is a
danger of contaminating the smoke switch with construc-
tion dust. This can considerably shorten the life span of the
smoke switch.
to
c
The retention force can be adjusted as required. According
to EN 1155, the extension torque for a door with 90°
holdopen should be 40 Nm–120 Nm.
CAUTION!
X
Check the freedom of movement of the rocker switch.
to
d
X
The protective cap must be removed when the hold-
open system is commissioned.
Initial switch-on, test
X
Remove the protective cap (if not already done).
X
Switch on the current (in case of TS 5000 RFS, additio-
nally via the lateral push button on the door closer).
Status display light is GREEN indicating that current is
being supplied to the electrical hold-open device (TS
5000 R) or free-swing door closer (TS 5000 RFS).
X
Engage the door leaf in the electrical hold-open device
(TS 5000 R) or open the door through >90° against the
closing force (TS 5000 RFS, freeswing activated).
X
Press the reset button on the smoke switch.
The status display turns YELLOW for approximately 4
seconds. The door closes. The status display then again
turns GREEN.
Acceptance test
An acceptance test must be carried out in order to ascer-
tainthe correct function and installation according to the
regulation, once the installation has been completed. For
this, follow the document “Instructions for the installation,
commissioning, operation and after-sales service mainte-
nance of GEZE hold-open system FA GC”.
Maintenance, care, repair
Regular servicing has to be carried out. For more informa-
tion on this, please observe the document “Instructions for
Installation, Commissioning, Operation and Maintenance of
the GEZE Hold-Open Device FA GC”.

GEZE TS 5000 R Specifications

General

Type	Overhead door closer
Door width	up to 1400 mm
Fire and smoke protection	Yes
Backcheck	Yes, adjustable
Closing speed	Adjustable
Latching action	Adjustable
Opening angle	up to 180°
Drive type	Mechanical
Hold-open function	Yes
