14
9 F. Attach front and rear supply shaft support brackets and insert
supply shafts
1. Match letter on support brackets, A through D, with letter on inside of side frame, letters face
in and are hidden when installed correctly
2. Remove bolts on side frame and use to bolt support brackets to side frames
3. Insert front and rear supply shaft in support brackets
1. Main machine
2. Supply shaft
3. Support brackets
